What is a horizontal plug-in testing machine?
In the fields of industrial production, quality inspection and R&D testing, the horizontal plug-in testing machine is an important equipment used to simulate plug-in actions and test the durability and reliability of connectors, cables, switches and other products. This article will introduce in detail the definition, functions, application scenarios and technical parameters of the horizontal plug-in testing machine to help readers fully understand this equipment.
1. Definition of horizontal plug-in testing machine
The horizontal plug-in and pull-out testing machine is a device specially used to test the performance of connectors, plugs, sockets and other products during repeated plug-in and pull-out processes. The "horizontal" in its name refers to the device's workbench or test platform being placed horizontally, in contrast to the vertical plug-in tester. The horizontal design is usually suitable for larger or heavier products under test and can provide a more stable testing environment.
2. Main functions of horizontal plug-in testing machine
Horizontal plug-in testing machine is mainly used for the following tests:
| Function | Description |
|---|---|
| Insertion and extraction force test | Measure the force change of the connector during the plugging and unplugging process to ensure that it meets the design requirements. |
| Durability test | Simulate long-term plugging and unplugging actions to test the service life of the product. |
| Contact resistance test | Detect changes in contact resistance during plugging and unplugging to evaluate electrical performance. |
| Mechanical strength test | Evaluate the mechanical structural stability of the product after repeated plugging and unplugging. |
3. Application scenarios of horizontal plug-in testing machine
Horizontal plug-in testing machines are widely used in many industries. The following are its main application areas:
| Industry | Application |
|---|---|
| Electronic appliances | Test USB interface, power socket, HDMI interface, etc. |
| automobile manufacturing | Evaluate the durability of automotive wiring harnesses and connectors. |
| Aerospace | Test the performance of high-reliability connectors. |
| medical device | Test the safety and stability of medical device connectors. |
4. Technical parameters of horizontal plug-in testing machine
The technical parameters of different models of horizontal plug-in testing machines may vary. The following are common parameter ranges:
| parameters | scope |
|---|---|
| Test speed | 5-60 times/minute |
| Plug and pull stroke | 10-100mm (adjustable) |
| Maximum testing force | 50-500N |
| Number of tests | 1-999,999 times (can be set) |
| Control method | PLC or touch screen control |
5. Advantages of horizontal plug-in testing machine
Compared with other types of plug-in testing machines, the horizontal plug-in testing machine has the following advantages:
1.High stability: Horizontal design makes the equipment more stable during testing and is suitable for testing larger or heavier products.
2.Easy to operate: The horizontal workbench is convenient for placing and fixing the samples to be tested, improving testing efficiency.
3.Wide range of applications: Can test multiple types of connectors and plugs to meet the needs of different industries.
4.Accurate data: Equipped with high-precision sensors and data acquisition systems to ensure the accuracy of test results.
6. How to choose a horizontal plug-in testing machine
When selecting a horizontal plug-in testing machine, the following factors need to be considered:
1.Testing requirements:Select the appropriate model based on the size, weight and testing requirements of the product being tested.
2.Technical parameters: Pay attention to whether the testing speed, stroke, maximum testing force and other parameters of the equipment meet the requirements.
3.Brand and after-sales service: Choose well-known brands to ensure equipment quality and after-sales support.
4.budget: Choose cost-effective equipment based on your budget.
7. Summary
The horizontal plug-and-pull testing machine is an indispensable equipment in the testing of connectors, cables and other products. Its stability, accuracy and wide applicability make it play an important role in many industries. Through the introduction of this article, I believe that readers will have a deeper understanding of the horizontal plug-in testing machine and be able to better select and use this equipment.
